Clamp-on Ultrasonic Flowmeter

​​​​​​
Stationary device,for installation at any location without process interruption or need to cut pipes
Accuracy: ±1%
Nominal diameter range: DN15…6000 / ½…240″
Max temperature: up to +160°C / +320°F;
Output: 4~20mA, Relay, RS485
Digtal communication: RS485 Modbus, HART
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button


Clamp-on Ultrasonic Flowmeter Principle of Operation

Clamp-on ultrasonic flowmeter principle is the use of ultrasonic sensors send out ultrasonic signals, propagation in the fluid and bounce back, and then by the sensor to receive, analyze, so as to deduce the fluid flow rate and flow. This kind of flowmeter will not touch the fluid, so it will not affect the fluidity, and has a wide range of measurement, accuracy and other advantages.

Clamp-on ultrasonic flowmeter can realize DN15~DN6000 pipeline flow measurement. Different sensors are suitable for different caliber ranges and different temperature ranges, with a wide range of applications. No need to break the pipe, easy to measure. No need to open the pipe sensor attached to the pipe to measure the flow. Installation is very convenient and quick.

Specification

Product Clamp-on Ultrasonic Flowmeter
Pipe Size 15mm-6000mm
Accuracy ±1%
Signal output 1 way 4-20mA output
1 way OCT pulse output
1 way replays output
Interface RS485, support MODBUS
Liquid Types Virtually all liquids
Working Temperature Convertor: -20~60℃; Flow Transducer: -30~160℃
Working humidity Convertor: 85%RH
Power Supply DC8~36V or AC85~264V(optional)
Date Logger Built-in data logger can store over 2000 lines of data
Case Material ABS
Dimension 170*180*56mm(Convertor)
Ultrasonic Water Flow Meter Supplier

Portable Ultrasonic Flow Meter

Ultrasonic Flow Meters OEMODM

Digital Ultrasonic Water Flowmeter

Functional Characteristics:

  1. Non-contact measurement method, There is no need to destroy the pipeline during the measurement process, no need to stop production, the clamp on flow meter does not contact the measured medium, and there is no pressure loss.

  2. Broad Pipe Size Compatibility:Suitable for pipes ranging from small to large diameters,typically from DN15 to DN6000,and compatible with various pipe materials. This clamp-on design offers significant cost savings,particularly for large-diameter pipes.

  3. Versatile Liquid Measurement:Capable of measuring both conductive and non-conductive liquids,making it suitable for water,oil,chemical liquids,and more

  4. Measurement range: The measurable flow rate range of the external clip-on is 0~10m/s.

  5. 8-36VDC, AC85-264V power supply modes are optional;

  6. Protection grade: IP68

  7. Process temperature: a) Standard clamp-on sensor: -30℃~90℃;
    b) High-temperature clamp-on sensor: -30℃~160℃;
    c) Plug-in sensor: -30℃~160℃;
    d) Pipe segment sensor: -30℃~160℃.

  8. Applicable pipes: Ultrasonic flow meters are suitable for various lined or unlined metal and plastic tight pipes. Such as steel, stainless steel, cast iron, cement pipe, copper, PVC, aluminum, fiberglass, etc.

Choose sensor


csb-!j

Portable ultrasonic flow meter application

Portable Ultrasonic Flowmeter
