Electromagnetic Flowmeter on How to Choose the Lining？

Choosing the right lining for an electromagnetic flowmeter is crucial for ensuring accurate measurements, longevity, and compatibility with the fluid being measured. The lining material protects the flowmeter's electrodes and internal components from corrosion, abrasion, and chemical attack. Electromagnetic flowmeter lining material should be selected according to the measured medium itself corrosive, temperature and abrasive. Here are the key factors to consider when selecting the lining:

1. Fluid Compatibility

• Chemical Resistance: The lining must be chemically compatible with the fluid being measured. Consider the pH, concentration, and chemical composition of the fluid.

• Temperature Range: Ensure the lining material can withstand the operating temperature of the fluid without degrading.

• Abrasion Resistance: For fluids containing solids or abrasive particles, choose a lining that resists wear and tear.

2. Common Lining Materials

• PTFE (Polytetrafluoroethylene):

• Excellent chemical resistance.

• Suitable for highly corrosive fluids (acids, alkalis, solvents).

• Temperature range: -40°C to 120°C.

• Not ideal for abrasive fluids.

• One of the more commonly used lining materials, with excellent corrosion resistance, general temperature resistance of up to 120 ℃, measuring a variety of acidic and alkaline media is preferred. So generally used for sanitary liquids or strongly corrosive liquids, such as concentrated acids and alkalis.

• PFA (Perfluoroalkoxy):

• Similar to PTFE but with better mechanical properties.

• Suitable for highly corrosive and high-purity fluids.

• Temperature range: -40°C to 180°C.

• PFA lining has strong corrosion resistance, temperature resistance up to 180 ℃, Commonly used in the food, beverage and pharmaceutical industries where strict hygiene is required.

• Polyurethane (PU)

• Excellent abrasion resistance.

• Suitable for slurries and abrasive fluids.

• Temperature range: -20°C to 60°C.

• Has excellent abrasion resistance, but poor corrosion resistance, and the temperature must not exceed 60 ℃. Generally used in industrial and mining environments that require high wear resistance, such as mineral slurry coal slurry and other media measurement.

• Neoprene

• Good for water, slurries, and mildly corrosive fluids.

• Excellent abrasion resistance.

• Temperature range varies by type (e.g., EPDM: -20°C to 120°C).

• Excellent elasticity, high tearing force, and good wear resistance. Resistant to erosion by general low-concentration acid, alkali and salt solutions, but not resistant to corrosion by oxidizing media <80°C; Measuring water, sewage, mud and mineral slurry.

• Ceramic Lining

• Good for water, slurries, and mildly corrosive fluids.

• Excellent abrasion resistance.

• Temperature range varies by type (e.g., EPDM: -20°C to 120°C).

• Excellent elasticity, high tearing force, and good wear resistance. Resistant to erosion by general low-concentration acid, alkali and salt solutions, but not resistant to corrosion by oxidizing media <80°C; Measuring water, sewage, mud and mineral slurry.

3. Application-Specific Considerations

• Water and Wastewater: EPDM or PTFE linings are commonly used.

• Acids and Alkalis: PTFE, PFA, or FEP linings are preferred.

• Slurries and Abrasive Fluids: Polyurethane or ceramic linings are ideal.

• Food and Beverage: PFA or PTFE linings are used for their high purity and chemical resistance.

• High-Temperature Fluids: Ceramic or PTFE linings are suitable.

4. Mechanical and Environmental Factors

• Pressure Rating: Ensure the lining can withstand the system's operating pressure.

• Flow Velocity: High-velocity flows may require more durable linings.

• Installation Environment: Consider external factors like UV exposure, humidity, and temperature fluctuations.

5. Cost and Maintenance

• Choose a lining that balances performance and cost.

• Consider the long-term maintenance requirements and replacement costs.

6. Manufacturer Recommendations

• Consult the flowmeter manufacturer for specific guidance on lining materials for your application.

• Review technical datasheets and compatibility charts provided by the manufacturer.

By carefully evaluating these factors, you can select the most suitable lining material for your electromagnetic flowmeter, ensuring optimal performance and durability.
