| Quantity: |
|---|
| Model Number | AEG 15 |
| Application | Gauge Pressure, Liquid Level |
| Connection Process | Clamp |
| Measuring Range | 0~3 Mpa |
| Overload Presure Limit(OPL) | Max 15 Mpa |
| Process Temperature | -40℃ ~ 150℃ |
| Ambient Temperature | -40℃ ~ 85℃ or -20℃ ~ 70℃(with LCD) |
| Reference Measurement Accuracy | ±0.2%URL or ±0.1%URL or ±0.075%URL(Optional) |
| Power Supply Voltage | 10~32 VDC |
| Output | 4~20 mA or 4~20mA+HART or MODBUS RS485 |
| Certificate | CE, NEPSI |
| Waterproof Grade | IP67 |
● Clamp-on pressure transmitter.
● A variety of diaphragms and process connections are available to meet hygienic requirements.
● Excellent temperature shock resistance, suitable for CIP/SIP process.
● Higher reliability and modular structure design, suitable for anti-condensation applications.
From hygiene regulations and food safety, to basic reliability and uptime requirements, producers of high-quality food and beverages around the world benefit from our extensive experience.
ARTang - Chinese Instrument Manufacturer
Focus on customer value, climb the peak of science and technology, Hangzhou ARTant Intelligent Equipment Co., Ltd. is a technology-based enterprise that provides customers with instruments for the automation industry.
Hangzhou ARTang concentrates on independent R&D and self- innovation. The tenet of the company is R&D, Quality First, Excellent Service. We strive to provide customers with one-stop measurement solution for the process automation industry. These services include technical consultation, product application, parameter calibration and personnel training, etc.
Automatic Calibration Line
Endress+Hauser Master Calibration
Gravimetric Calibration
Machining Workshop
Welding Proccess
Flange Process
Accuracy Calibration
Packaging
| Model Number | AEG 15 |
| Application | Gauge Pressure, Liquid Level |
| Connection Process | Clamp |
| Measuring Range | 0~3 Mpa |
| Overload Presure Limit(OPL) | Max 15 Mpa |
| Process Temperature | -40℃ ~ 150℃ |
| Ambient Temperature | -40℃ ~ 85℃ or -20℃ ~ 70℃(with LCD) |
| Reference Measurement Accuracy | ±0.2%URL or ±0.1%URL or ±0.075%URL(Optional) |
| Power Supply Voltage | 10~32 VDC |
| Output | 4~20 mA or 4~20mA+HART or MODBUS RS485 |
| Certificate | CE, NEPSI |
| Waterproof Grade | IP67 |
● Clamp-on pressure transmitter.
● A variety of diaphragms and process connections are available to meet hygienic requirements.
● Excellent temperature shock resistance, suitable for CIP/SIP process.
● Higher reliability and modular structure design, suitable for anti-condensation applications.
From hygiene regulations and food safety, to basic reliability and uptime requirements, producers of high-quality food and beverages around the world benefit from our extensive experience.
ARTang - Chinese Instrument Manufacturer
Focus on customer value, climb the peak of science and technology, Hangzhou ARTant Intelligent Equipment Co., Ltd. is a technology-based enterprise that provides customers with instruments for the automation industry.
Hangzhou ARTang concentrates on independent R&D and self- innovation. The tenet of the company is R&D, Quality First, Excellent Service. We strive to provide customers with one-stop measurement solution for the process automation industry. These services include technical consultation, product application, parameter calibration and personnel training, etc.
Automatic Calibration Line
Endress+Hauser Master Calibration
Gravimetric Calibration
Machining Workshop
Welding Proccess
Flange Process
Accuracy Calibration
Packaging
About ARTang
ARTang is a global leader in measurement instrumentation, services and solutions for industrial process engineering that energizes the transformation of society and industry to achieve a more productive, sustainable future. We provide process solutions for flow, level, pressure, analytics and digital communications, optimizing processes in terms of economic efficiency, safety & environmental impact.
