ACS11 Digital Conductivity Sensor




Measurement range:
Conductivity measurement range: k=0.5 (0～200mS/cm)
Temperature measurement range: 0～60℃
Measurement range:
Conductivity measurement range: k=0.5 (0～200mS/cm)
Temperature measurement range: 0～60℃
Availability:
Quantity:
Inquire

facebook sharing button
twitter sharing button
line sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

|

 Product Description

ProductDigital Conductivity Sensor
ModelACS11
Measure rangek=0.5（0～200mS/cm）
Temperature range 0-60℃/high temp up to 120℃
 Accuracy Conductivity measurement accuracy: 2%
Temperature measurement accuracy: ±0.5℃
Working temperature0～80℃
Storage environment-20～70℃
  Ingress protection IP65
Housing MaterialABS
Cable5 meters (standard)

|

 Comment & FAQ

ACS 11 Digital conductivity sensor of online conductivity electrode, adopt electrode measuring method, and realizes the automatic temperature compensation in the interior of the electrodes, Automatic identification of standard solution. Electrode adopt imported composite electrode, high precision, good stability,long lifetime, with rapid response, low maintenance cost, real-time online measurement characters etc.. The electrode using standard Modbus RTU (485) communication protocol, 24V DC power supply, four wire mode can very convenient access to sensor networks.

Product Features

1. Low maintenance required;

2. The design of quadrupole conductivity electrode can avoid the measurement error caused by electrode polarization and make the measurement more accurate;

3. can be applied to conductivity measurement in aqueous solution.
