Introduction
glass pH sensor is widely used in wastewater treatment and fields including mining and smelting, papermaking, paper pulp, textiles, petrochemical industry, process of semiconductor electronic industry and downstream engineering of biotechnology.
|
Specification
| Product | high temperature ph sensor |
| Model | APS 13 |
| Measuring range | 0-14pH |
| Temperature range | 0～145℃ |
| Pressure resistance | 0~6Bar at 25℃ |
| 5Bar at 130℃ 0~6Bar |
| Accuracy | ±0.05pH |
| Resolution | 0.01pH |
| Internal resistance | ≤250MΩ (25℃) |
| Protection level | IP56 |
| Housing material | Glass electrode |
| Process connection | Upper and lower NPT3/4 external thread |
| Cable | Low noise cable |
|
high temperature ph electrode features:
Adopting high temperature resistant gel and high temperature resistant solid medium double liquid junction structure, the electrode can withstand 0.6MPao without reverse pressure and can be directly used for high temperature disinfection at 130℃
No need to replenish dielectric, low maintenance
Adopting S8, VP, K8S and other cable interfaces, it can be used interchangeably with imported brand non-digital electrodes
The electrode length is 120, 150, 225, 325, 425mm and can be selected according to needs
No need to replenish dielectric, low maintenance
